Ultra Star-M UVSM.
Highly matte ink solution
Ultra Star-M UVSM UV-curing screen printing ink is highly matt and very versatile for use in graphic and industrial screen printing. Also used in the flatbed label printing segment. Very good adhesion on a variety of plastics.
- Universal, UV-curable ink with highly matt finish
- High chemical and mechanical resistances
- High opacity
Substrates:
- Paper, corrugated paper
- PVC, rigid
- Self-adhesive PVC foil
- Polystyrene (PS)
- ABS
- SAN
- Polyproylen (PP), treated
- Polyethylene (PE), pre-treated
- Polycarbonate (PC)
Industry solution for:
- Graphic printing
- Industrial printing
Highlights:
- Universal, UV-curable ink with highly matt finish
- High chemical and mechanical resistances
- High opacity
Light Yellow
Medium Yellow
Orange
Scarlet Red
Carmine Red
Magenta
Violet
Ultramarine Blue
Brilliant Blue
Blue Green
Grass Green
White
Black
Transparent Base
Special Binder
37210057922
37210057924
37210057926
37210057932
37210057934
37210057936
37210057950
37210057952
37210057956
37210057960
37210057962
37210057970
37210057980
37210057409
37210057904
Opaque Black
Opaque Black
White
37210058180
37210058181
37210058970
- Basic Shades922
Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
Light Yellow 922, 1 kg
37210057922Medium Yellow 924, 1 kg
37210057924Orange 926, 1 kg
37210057926Scarlet Red 932, 1 kg
37210057932Carmine Red 934, 1 kg
37210057934Magenta 936, 1 kg
37210057936Violet 950, 1 kg
37210057950Ultramarine Blue 952, 1 kg
37210057952Brilliant Blue 956, 1 kg
37210057956Blue Green 960, 1 kg
37210057960Grass Green 962, 1 kg
37210057962White 970, 1 kg
37210057970Black 980, 1 kg
37210057980Transparent Base 409, 1 kg
37210057409Special Binder 904, 1 kg
37210057904 - High Opaque Shades180
Opaque Black
181Opaque Black
Basic Shades970White
Opaque Black 180, 5 kg
37210058180Opaque Black 181, 5 kg
37210058181White 970, 5 kg
37210058970
Properties:
- UV Screen printing ink for PVC, pre-treated self-adhesive PE/PP films, polyester films, PS, PC, rigid PVC, paper, cardboard
- Matt, fast curing, good opacity, high chemical resistance, versatile use
Substrates:
- Paper, corrugated paper
- PVC, rigid
- Self-adhesive PVC foil
- Polystyrene (PS)
- ABS
- SAN
- Polyproylen (PP), treated
- Polyethylene (PE), pre-treated
- Polycarbonate (PC)
Auxiliaries:
| UVV2 | Thinner | 1 - 10 % |
| UV-HV4 | Adhesion Modifier | 0.5 - 4 % |
| H1 | Hardener | 2 % |
| UV-B1 | UV Accelerator | 1 - 2 % |
| STM | Thickening Agent | 0.5 - 2 % |
| UV-VM | Levelling Agent | 0.5 - 1.5 % |
| UR3 | Cleaner (flp. 42°C) | |
| UR4 | Cleaner (flp. 52°C) | |
| UR5 | Cleaner (flp. 72°C) |
Ink adjustment:
All Ultra Star-M UVSM basic shades have a very evenly, matt appearance, as well as good opacity. The shades are not brilliant due to the matting agent.
The smell of the ink is nearly undetectable during printing, as well as after the curing process.Drying:
The curing speed of the ink is generally dependant upon the kind of UV-curing unit (reflectors), number, age, and power of the UV-lamps, the printed ink film thickness, colour shade, substrate in use, as well as the printing speed.
Ultra Star-M UVSM is a post-curing UV ink which will achieve its final adhesion and resistances after 24 hours. The ink film should pass a cross hatch tape test after having cooled down to room temperature.
Printing parameters:
Selection of fabric depends on the printing conditions, the desired curing speed and ink mileage as well as the required opacity. Generally, fabrics of 120-34 to 180-27 can be used. A uniform screen tension (>16 N) ensures even ink layers.
UV curable inks can be processed with all commercially available stencil techniques such as capillary films (15-20µ) or solvent-resistant photo emulsions.- Paper, corrugated paper
- PVC, rigid
- Self-adhesive PVC foil
- Polystyrene (PS)
- ABS
- SAN
- Polyproylen (PP), treated
- Polyethylene (PE), pre-treated
- Polycarbonate (PC)
- Graphic printing
- Industrial printing
- Universal, UV-curable ink with highly matt finish
- High chemical and mechanical resistances
- High opacity
Substrates:
Industry solution for:
Highlights:
- Basic Shades922
Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
Light Yellow 922, 1 kg
37210057922Medium Yellow 924, 1 kg
37210057924Orange 926, 1 kg
37210057926Scarlet Red 932, 1 kg
37210057932Carmine Red 934, 1 kg
37210057934Magenta 936, 1 kg
37210057936Violet 950, 1 kg
37210057950Ultramarine Blue 952, 1 kg
37210057952Brilliant Blue 956, 1 kg
37210057956Blue Green 960, 1 kg
37210057960Grass Green 962, 1 kg
37210057962White 970, 1 kg
37210057970Black 980, 1 kg
37210057980Transparent Base 409, 1 kg
37210057409Special Binder 904, 1 kg
37210057904 - High Opaque Shades180
Opaque Black
181Opaque Black
Basic Shades970White
Opaque Black 180, 5 kg
37210058180Opaque Black 181, 5 kg
37210058181White 970, 5 kg
37210058970
Available in these sizes / volumesBasic Shades922Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
Light Yellow 922, 1 kg
37210057922Medium Yellow 924, 1 kg
37210057924Orange 926, 1 kg
37210057926Scarlet Red 932, 1 kg
37210057932Carmine Red 934, 1 kg
37210057934Magenta 936, 1 kg
37210057936Violet 950, 1 kg
37210057950Ultramarine Blue 952, 1 kg
37210057952Brilliant Blue 956, 1 kg
37210057956Blue Green 960, 1 kg
37210057960Grass Green 962, 1 kg
37210057962White 970, 1 kg
37210057970Black 980, 1 kg
37210057980Transparent Base 409, 1 kg
37210057409Special Binder 904, 1 kg
37210057904High Opaque Shades180Opaque Black
181Opaque Black
Basic Shades970White
Opaque Black 180, 5 kg
37210058180Opaque Black 181, 5 kg
37210058181White 970, 5 kg
37210058970- UV Screen printing ink for PVC, pre-treated self-adhesive PE/PP films, polyester films, PS, PC, rigid PVC, paper, cardboard
- Matt, fast curing, good opacity, high chemical resistance, versatile use
- Paper, corrugated paper
- PVC, rigid
- Self-adhesive PVC foil
- Polystyrene (PS)
- ABS
- SAN
- Polyproylen (PP), treated
- Polyethylene (PE), pre-treated
- Polycarbonate (PC)
Properties:
Substrates:
Auxiliaries:
UVV2 Thinner 1 - 10 % UV-HV4 Adhesion Modifier 0.5 - 4 % H1 Hardener 2 % UV-B1 UV Accelerator 1 - 2 % STM Thickening Agent 0.5 - 2 % UV-VM Levelling Agent 0.5 - 1.5 % UR3 Cleaner (flp. 42°C) UR4 Cleaner (flp. 52°C) UR5 Cleaner (flp. 72°C) Ink adjustment:
All Ultra Star-M UVSM basic shades have a very evenly, matt appearance, as well as good opacity. The shades are not brilliant due to the matting agent.
The smell of the ink is nearly undetectable during printing, as well as after the curing process.Drying:
Ultra Star-M UVSM is a fast curing UV-ink. A UV-curing unit with either two medium-pressure mercury lamps (80-120 W/cm) or one medium-pressure mercury lamp (120-180W/cm) cures Ultra Star-M UVSM at a belt speed of 10-25 m/min.
The curing speed of the ink is generally dependant upon the kind of UV-curing unit (reflectors), number, age, and power of the UV-lamps, the printed ink film thickness, colour shade, substrate in use, as well as the printing speed.
Ultra Star-M UVSM is a post-curing UV ink which will achieve its final adhesion and resistances after 24 hours. The ink film should pass a cross hatch tape test after having cooled down to room temperature.Printing parameters:
Selection of fabric depends on the printing conditions, the desired curing speed and ink mileage as well as the required opacity. Generally, fabrics of 120-34 to 180-27 can be used. A uniform screen tension (>16 N) ensures even ink layers.
UV curable inks can be processed with all commercially available stencil techniques such as capillary films (15-20µ) or solvent-resistant photo emulsions.
