Ultra Pack UVFP.
Low-migration ink for plastic packaging
Ultra Pack UVFP is a low-migration UV screen printing ink for exterior surface printing onto food, cosmetics, and beverage packaging made of pre-treated PE and PP. Special formula minimizes the risk of subsequent substance transfer from the outer decoration into the content.
- Low-migration formulation
- High resistance to water, steam, various filling goods, and chemicals
- Good adhesion and very flexible ink film, suitable for tubes
- Press-ready for easy handling
Substrates:
- Polyethylene (PE), pre-treated
- Polyproylen (PP), treated
- HDPE
Industry solution for:
- Food packaging
- Cosmetics packaging
- Beverage packaging
Highlights:
Low-Migration ink with special selection and purity
criteria of the raw material
- All used ingredients are listed in the Swiss “Verordnung des EDI über Bedarfsgegenstände” (SR 817.023.21)
- Compliance with the “EuPIA Suitability List of Photo-Initiators for Low Migration UV Printing Inks and Varnishes” part 1A
- Corresponding to the “Nestlé Guidance Note on Packaging Inks”
- Pigments corresponding to “Resolution AP (89)1”
- No use of Bisphenol A (BPA)
- Produced in accordance with the requirements for indirect food contact of the “EuPIA-GMP”
Good adhesion, flexible ink film
- Suitable for tubes and water bottles
High reactivity, good curing
- Time and cost saving
Resistant to water, steam, various filling goods, or chemicals
- For maximum quality and process safety
Ideal shear and flow properties, press-ready, single component for optimised low migration use
- Perfect printing characteristics for easy handling
Excellent appearance
- Brilliant color shades with high gloss
- High opacity
Available in these sizes / volumes
4-Colour Process Shades Standard
425
Process Yellow
435
Process Magenta
455
Process Cyan
485
Process Black
High Opaque Shades
170
Opaque White
171
Opaque White, silicone-free
180
Opaque Black
Basic Shades
922
Light Yellow
924
Medium Yellow
926
Orange
932
Scarlet Red
934
Carmine Red
936
Magenta
950
Violet
952
Ultramarine Blue
956
Brilliant Blue
960
Blue Green
962
Grass Green
970
White
980
Black
Further Products
409
Transparent Base
904
Special Binder
910
Overprint Varnish
Process Yellow 425, 1 kg
37490057425
37490057425
Process Magenta 435, 1 kg
37490057435
37490057435
Process Cyan 455, 1 kg
37490057455
37490057455
Process Black 485, 1 kg
37490057485
37490057485
Opaque White 170, 1 kg
37490057170
37490057170
Opaque White, silicone-free 171, 1 kg
37490057171
37490057171
Opaque Black 180, 1 kg
37490057180
37490057180
Light Yellow 922, 1 kg
37490057922
37490057922
Medium Yellow 924, 1 kg
37490057924
37490057924
Orange 926, 1 kg
37490057926
37490057926
Scarlet Red 932, 1 kg
37490057932
37490057932
Carmine Red 934, 1 kg
37490057934
37490057934
Magenta 936, 1 kg
37490057936
37490057936
Violet 950, 1 kg
37490057950
37490057950
Ultramarine Blue 952, 1 kg
37490057952
37490057952
Brilliant Blue 956, 1 kg
37490057956
37490057956
Blue Green 960, 1 kg
37490057960
37490057960
Grass Green 962, 1 kg
37490057962
37490057962
White 970, 1 kg
37490057970
37490057970
Black 980, 1 kg
37490057980
37490057980
Transparent Base 409, 1 kg
37490057409
37490057409
Special Binder 904, 1 kg
37490057904
37490057904
Overprint Varnish 910, 1 kg
37490057910
37490057910
- 4-Colour Process Shades Standard425
Process Yellow
435Process Magenta
455Process Cyan
485Process Black
High Opaque Shades170Opaque White
171Opaque White, silicone-free
180Opaque Black
Basic Shades922Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
910Overprint Varnish
Process Yellow 425, 1 kg
37490057425Process Magenta 435, 1 kg
37490057435Process Cyan 455, 1 kg
37490057455Process Black 485, 1 kg
37490057485Opaque White 170, 1 kg
37490057170Opaque White, silicone-free 171, 1 kg
37490057171Opaque Black 180, 1 kg
37490057180Light Yellow 922, 1 kg
37490057922Medium Yellow 924, 1 kg
37490057924Orange 926, 1 kg
37490057926Scarlet Red 932, 1 kg
37490057932Carmine Red 934, 1 kg
37490057934Magenta 936, 1 kg
37490057936Violet 950, 1 kg
37490057950Ultramarine Blue 952, 1 kg
37490057952Brilliant Blue 956, 1 kg
37490057956Blue Green 960, 1 kg
37490057960Grass Green 962, 1 kg
37490057962White 970, 1 kg
37490057970Black 980, 1 kg
37490057980Transparent Base 409, 1 kg
37490057409Special Binder 904, 1 kg
37490057904Overprint Varnish 910, 1 kg
37490057910
Properties:
- UV-curable screen printing ink for pretreated polyethylene and polypropylene, designed as food packaging ink for printing on the non-food contact side, proven low migration based on real-life parameters
- Fast curing, high degree of gloss, excellent water and filler resistance, thixotropic adjustment, flexible ink film, universal use
Substrates:
- Polyethylene (PE), pre-treated
- Polyproylen (PP), treated
- HDPE
Auxiliaries:
| G-HX | Hardener | 5 % |
| UR4 | Cleaner (flp. 52°C) | |
| UR5 | Cleaner (flp. 72°C) | |
| G-UR5 | Cleaner (flp. 72°C) |
Ink adjustment:
Attention: Low-migration ink
Use only thoroughly cleaned stencils, squeegees, pumps, tubes, and injectors to prevent contamination.
- Stir thoroughly to ensure homogeneous mixing
- When using as a 2-component ink, mix the hardener thoroughly
- Do not process below 15 °C
- Avoid exposure to high humidity after printing
- Let the mixture rest for 15 min before use
- Pot life: 8 h at 20-25 °C and 45-60 % RH
Drying:
- UV curing: 120-200 W/cm, suitable for speeds up to 5,000 bottles/h
- Post-curing within 24 h
- Cure waste prints completely
Printing parameters:
Mesh: 140-31 to 180-31.
Stencils: Capillary films (15–20 µm) or emulsions and combination stencils.
- Polyethylene (PE), pre-treated
- Polyproylen (PP), treated
- HDPE
- Food packaging
- Cosmetics packaging
- Beverage packaging
- All used ingredients are listed in the Swiss “Verordnung des EDI über Bedarfsgegenstände” (SR 817.023.21)
- Compliance with the “EuPIA Suitability List of Photo-Initiators for Low Migration UV Printing Inks and Varnishes” part 1A
- Corresponding to the “Nestlé Guidance Note on Packaging Inks”
- Pigments corresponding to “Resolution AP (89)1”
- No use of Bisphenol A (BPA)
- Produced in accordance with the requirements for indirect food contact of the “EuPIA-GMP”
- Suitable for tubes and water bottles
- Time and cost saving
- For maximum quality and process safety
- Perfect printing characteristics for easy handling
- Brilliant color shades with high gloss
- High opacity
Substrates:
Industry solution for:
Highlights:
Low-Migration ink with special selection and puritycriteria of the raw materialGood adhesion, flexible ink filmHigh reactivity, good curingResistant to water, steam, various filling goods, or chemicalsIdeal shear and flow properties, press-ready, single component for optimised low migration useExcellent appearance- 4-Colour Process Shades Standard425
Process Yellow
435Process Magenta
455Process Cyan
485Process Black
High Opaque Shades170Opaque White
171Opaque White, silicone-free
180Opaque Black
Basic Shades922Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
910Overprint Varnish
Process Yellow 425, 1 kg
37490057425Process Magenta 435, 1 kg
37490057435Process Cyan 455, 1 kg
37490057455Process Black 485, 1 kg
37490057485Opaque White 170, 1 kg
37490057170Opaque White, silicone-free 171, 1 kg
37490057171Opaque Black 180, 1 kg
37490057180Light Yellow 922, 1 kg
37490057922Medium Yellow 924, 1 kg
37490057924Orange 926, 1 kg
37490057926Scarlet Red 932, 1 kg
37490057932Carmine Red 934, 1 kg
37490057934Magenta 936, 1 kg
37490057936Violet 950, 1 kg
37490057950Ultramarine Blue 952, 1 kg
37490057952Brilliant Blue 956, 1 kg
37490057956Blue Green 960, 1 kg
37490057960Grass Green 962, 1 kg
37490057962White 970, 1 kg
37490057970Black 980, 1 kg
37490057980Transparent Base 409, 1 kg
37490057409Special Binder 904, 1 kg
37490057904Overprint Varnish 910, 1 kg
37490057910
Available in these sizes / volumes4-Colour Process Shades Standard425Process Yellow
435Process Magenta
455Process Cyan
485Process Black
High Opaque Shades170Opaque White
171Opaque White, silicone-free
180Opaque Black
Basic Shades922Light Yellow
924Medium Yellow
926Orange
932Scarlet Red
934Carmine Red
936Magenta
950Violet
952Ultramarine Blue
956Brilliant Blue
960Blue Green
962Grass Green
970White
980Black
Further Products409Transparent Base
904Special Binder
910Overprint Varnish
Process Yellow 425, 1 kg
37490057425Process Magenta 435, 1 kg
37490057435Process Cyan 455, 1 kg
37490057455Process Black 485, 1 kg
37490057485Opaque White 170, 1 kg
37490057170Opaque White, silicone-free 171, 1 kg
37490057171Opaque Black 180, 1 kg
37490057180Light Yellow 922, 1 kg
37490057922Medium Yellow 924, 1 kg
37490057924Orange 926, 1 kg
37490057926Scarlet Red 932, 1 kg
37490057932Carmine Red 934, 1 kg
37490057934Magenta 936, 1 kg
37490057936Violet 950, 1 kg
37490057950Ultramarine Blue 952, 1 kg
37490057952Brilliant Blue 956, 1 kg
37490057956Blue Green 960, 1 kg
37490057960Grass Green 962, 1 kg
37490057962White 970, 1 kg
37490057970Black 980, 1 kg
37490057980Transparent Base 409, 1 kg
37490057409Special Binder 904, 1 kg
37490057904Overprint Varnish 910, 1 kg
37490057910- UV-curable screen printing ink for pretreated polyethylene and polypropylene, designed as food packaging ink for printing on the non-food contact side, proven low migration based on real-life parameters
- Fast curing, high degree of gloss, excellent water and filler resistance, thixotropic adjustment, flexible ink film, universal use
- Polyethylene (PE), pre-treated
- Polyproylen (PP), treated
- HDPE
- Stir thoroughly to ensure homogeneous mixing
- When using as a 2-component ink, mix the hardener thoroughly
- Do not process below 15 °C
- Avoid exposure to high humidity after printing
- Let the mixture rest for 15 min before use
- Pot life: 8 h at 20-25 °C and 45-60 % RH
- UV curing: 120-200 W/cm, suitable for speeds up to 5,000 bottles/h
- Post-curing within 24 h
- Cure waste prints completely
Properties:
Substrates:
Auxiliaries:
G-HX Hardener 5 % UR4 Cleaner (flp. 52°C) UR5 Cleaner (flp. 72°C) G-UR5 Cleaner (flp. 72°C) Ink adjustment:
Attention: Low-migration inkUse only thoroughly cleaned stencils, squeegees, pumps, tubes, and injectors to prevent contamination.Drying:
Printing parameters:
Mesh: 140-31 to 180-31.Stencils: Capillary films (15–20 µm) or emulsions and combination stencils.
